MAPRE Dual Longitudinal Taping Head TRLB 400-1M

Tape material: Aluminium, PP, PE, Paper

Tape width: 12 to 40mm

Tape thickness: 0,020 to 0,040mm

Tension adjustable by potentiometer:

• range 1: 0,5 to 2,5daN
• range 2 : 1,5 to 5,0daN
• Range 3 : 2,5 to 10,0daN

Pad diameter: 300mm

Pad width: 330mm

Pad hold on shaft: 76mm diameter

Pad weight: 56kg

Linear speed: up to 200m/min
