MAPRE 80mm 25D HFFR Extruder, Model E1.80
Gallery:
0301-00262
Compact 80mm 25D Extruder made in 2001
Working height: 1000mm
Materials: PVC, PE, LSH
Diameter before insulation: 2 to 8mm
Diameter after insulation: 3 to 14mm (up to 35mm possible by changing the crosshead)
Speed: 300m/min
Extruder Output: 300kg/h PVC (1,35 kg/dm³)
Electrical panel built in the machine frame
Delivery includes:
* 1 x 80mm 25D Extruder
* 1 x Self Centering Crosshead (up to 12mm diameter)
* DC 112kW Motor
* Piovan Dosing Unit
* Moretto Hopper Loader
Type: Extruders
Model: E1.80-25D
Quantity available: 1
